ASTM C518 Thermal Resistance Test
If you need a reliable test lab to perform thermal resistance and conductivity testing, turn to VTEC Laboratories. We offer fast, reliable R-value testing using ASTM C518, with thermal conductivity calculated from the results. We do this for many different industries, and can do just that for your organization.
What Is ASTM C518 Testing?
This testing is a standardized method used to determine materials' steady-state thermal transmission properties using a heat flow meter apparatus. Established by the American Society for Testing and Materials (ASTM), this test evaluates a material's ability to resist heat transfer, making it an essential tool for many industries. It is also known as the Standard Test Method for Steady-State Thermal Transmission Properties by means of the Heat Flow Meter Apparatus.
By quantifying a material's thermal insulation properties, the test helps in the selection of appropriate materials for energy-efficient designs and products.
This test is most commonly used to derive an accurate measurement of how effective insulation is. The ASTM C518 test can generate a K-Value (thermal conductivity) and an R-Value (thermal resistance). With these measurements, you can demonstrate that a particular material meets federal regulations for insulation materials, as well as show customers how a certain material may be superior to others as insulation. This is a building code requirement for insulation and systems.
Scope of the Standard Test Method for Steady-State Thermal Transmission Properties by Means of the Heat Flow Meter Apparatus
ASTM C518's scope extends to a wide range of materials, including but not limited to insulation products, building materials, textiles and composites. This standard test method provides a reliable, consistent approach to thermal resistance testing, often referred to as R-value testing, by measuring how well a material resists heat flow under steady-state conditions. From these measurements, ASTM C518 thermal conductivity values can also be calculated, offering insights into its ability to regulate temperature and conserve energy.
ASTM C518 Standard Testing Method
The testing procedure involves placing a specimen between two plates in a heat flow meter apparatus. One plate is heated while the other is cooled, creating a controlled temperature gradient across the specimen. Heat flows from the warm plate to the cool one through the sample. The heat flow rate and temperature difference across the specimen are measured to calculate its thermal conductivity, thermal transmittance and thermal resistance.
Other Common Tests Performed With ASTM C518
This testing is used by various industries that require accurate assessments of thermal transmission properties in materials. Insulation materials like foam, fiberglass and mineral wood can undergo ASTM C518 testing to determine their effectiveness in regulating heat flow. In addition to insulation, we can use this test to gauge the thermal conductivity and thermal resistance properties in the construction sector for substances like window materials and other energy-efficient construction materials like walls, roofs and floors.
This type of thermal resistance testing also benefits industries involving manufacturing appliances, electronics and automotive components. Manufacturers can use the results of the test to design products that manage heat effectively, preventing overheating and ensuring optimal performance. The energy industry employs ASTM C518 to evaluate materials used in thermal insulation for pipelines and equipment.
In some cases, you may wish to use this test instead of the ASTM C177. The ASTM C177 test is essentially the same, but uses a Guarded Hot Plate Apparatus instead of a Heat Flow Meter Apparatus.
The ASTM C518 test provides valuable information about a material's thermal performance. The results obtained include:
- Thermal conductivity: Indicates how effectively the material conducts heat.
- Thermal resistance: Signifies the material's ability to resist heat flow.
- Thermal transmittance: Characterizes the overall heat transfer through a construction assembly.
For instance, in the construction industry, the thermal conductivity ASTM results and others above guide the selection of insulating materials. A higher thermal resistance value indicates better insulation, helping maintain comfortable indoor temperatures while reducing energy consumption. Manufacturers also benefit from this testing as it assists in designing energy-efficient products and complying with industry standards.
ASTM C518 thermal resistance testing or R-value testing is a vital tool for evaluating the thermal transmission properties of materials. Its standardized approach offers valuable insights into how well materials resist heat flow, making it essential for industries striving for energy efficiency and optimal product performance.
Choose VTEC for Your Physical Testing Needs
VTEC Laboratories can perform a wide range of testing, including materials testing, physical testing and thermal analysis. We have over 30 years of thermal analysis and properties testing experience for industries ranging from aerospace, manufacturing and military to chemical, electronics and transportation. We have analyzed thermal properties for building materials, laminates, composites, adhesives and more.
Our top-level engineers are extremely knowledgeable about ASTM C518 testing and can perform custom tests. We are an ISO 17020, 17025 and 17065-accredited laboratory that has been a trusted source of lab tests since 1982. We meet the testing standards of over 20 different regulatory organizations.
Request a Quote for ASTM C518 Testing Today
Ready to evaluate your material's thermal performance? Turn to the experts at VTEC Labs. Ensure energy efficiency and product excellence with precise insights into thermal conductivity, resistance and transmittance. Drive innovation and more informed decision-making by harnessing the power of standardized testing.
At VTEC Labs, we offer the fastest thermal resistance testing turnaround times in the industry. You can expect your results within two weeks after test completion. For projects with tighter deadlines, talk to our team. We can work to deliver your testing results according to your specific timeline.
To learn more about how VTEC Labs can help with your ASTM C518 testing needs or to request a quote, contact us today.
